Square Baler

RELIABLE, HARD-WORKING BALERS

Operators who custom bale, especially for horse farms, are big fans of New Holland square balers. New Holland bales are the only choice for hand-feeding because they quickly separate into flakes. Professionals put their trust in BC5000 model balers because they make consistently dense, well-shaped bales that are easy to handle.

Bale Size:
Cross Section
Length
14 x 18 in. (36x 46 cm)
Audjustable,12 to 52 in. (31 to 132 cm)

Super-Sweep Pickup:
Width on flare
Number of teeth
Floating windguard
Drive
Gauge wheel
1.8 m
110 on 5 tooth bars
8 rods
V-belt roller chain to lost motion reel drive
3.00 x 12; semi-pneumatic

Rotary Feeding System:
Type
Drive
Packer fork in combination with 2 paired rotors
Chain from main drive shaft; sealed ball bearings on all shafts

Feed opening Plunger:
Stroke length
Speed (540 rpm)
Construction
1826 cm
76.2 cm
93 SPM
High-strength steel throughout; modified extension is built
into the plunger face, eleminating the need for bolt-on extensions

Tying Mechanisms:
Type
protection
Capicity (twine)
Capacity(wire)
HD Knotter
Shearbolt
6 balls
4 coils

Main Drive:
Flywheel diameter
PTO
Protection
Gearbox
56 cm
3 joint
Hearbolt, overrunning & slip clutches
poid with tapered roller bearings; heat-treated alloy Tires: steel running in oil

TYRES:
Floating (right)
Floating (left)
27 x 9.50-15, 6 PR
31 x 13.50,5, 6 PR

Dimensions: Height (max.)
Width
178 cm
279 cm

Length
626 cm

Weight:
With 3-joint PTO & quarter-turn bale chute
1542 kg

Recommended Transport Speed: 32 km/h

Tractor requirement: SS-75 HP

Hydroformatic Bale Tensioning:
- Hydroformatic System: Hydroformatic bale tensioning is a system used in balers to maintain consistent and uniform bale density. It typically involves a hydraulic system that adjusts the tension applied to the bale during the baling process.
- Benefits: This system allows for efficient and precise control of bale density, ensuring that the resulting bales are well-formed and consistent in size.
HD Knotter:
- HD (Heavy Duty) Knotter: This terminology suggests that the knotter mechanism in the baler is designed with heavy-duty components. Knotter systems are crucial in balers for tying the bales securely after they are formed.
- Benefits: A heavy-duty knotter is designed for durability and reliability, especially when dealing with high volumes of baling.

Bale Size: Cross Section Length	14 x 18 in. (36x 46 cm) Audjustable,12 to 52 in. (31 to 132 cm)
Super-Sweep Pickup: Width on flare Number of teeth Floating windguard Drive Gauge wheel	1.8 m 110 on 5 tooth bars 8 rods V-belt roller chain to lost motion reel drive 3.00 x 12; semi-pneumatic
Rotary Feeding System: Type Drive	Packer fork in combination with 2 paired rotors Chain from main drive shaft; sealed ball bearings on all shafts
Feed opening Plunger: Stroke length Speed (540 rpm) Construction	1826 cm 76.2 cm 93 SPM High-strength steel throughout; modified extension is built into the plunger face, eleminating the need for bolt-on extensions
Tying Mechanisms: Type protection Capicity (twine) Capacity(wire)	HD Knotter Shearbolt 6 balls 4 coils
Main Drive: Flywheel diameter PTO Protection Gearbox	56 cm 3 joint Hearbolt, overrunning & slip clutches poid with tapered roller bearings; heat-treated alloy Tires: steel running in oil
TYRES: Floating (right) Floating (left)	27 x 9.50-15, 6 PR 31 x 13.50,5, 6 PR
Dimensions: Height (max.) Width	178 cm 279 cm
Length	626 cm
Weight: With 3-joint PTO & quarter-turn bale chute	1542 kg
Recommended Transport Speed:	32 km/h
Tractor requirement:	SS-75 HP
