Tractor Mounted Sprayer

With the help of our state-of-the-art manufacturing unit and a team of adroit professionals, we have become one of the foremost names in the market

Tractor Mounted Sprayer

With the help of our state-of-the-art manufacturing unit and a team of adroit professionals, we have become one of the foremost names in the market

Tractor Mounted Sprayer

Tractor Mounted Sprayer

With the help of our state-of-the-art manufacturing unit and a team of adroit professionals, we have become one of the foremost names in the market by offering high grade Agricultural Tractor Pesticide Sprayer. This sprayer is fabricated using the finest quality raw material, with the help of modern technology that ensures its accuracy and quality. The offered range of Agricultural Tractor Pesticide Sprayer is acknowledged amongest our clients due to its trouble free performance and sturdy construction. We offer this sprayer to our clients in various specifications, at market leading prices.

Model No. Crop master
Tank Capacity 400 Liter
Sprayer Unit Tractor Mounted Gun jet Sprayer
Working Pressure Ideally 35-40 bars
Pressure Adjustment 1-50 bars
RPM PTO rpm 540
Pump Discharge Rate 36-50 LPM @ 950 RPM
HP Required 35 HP Tractor
Horse Size 8.5 or 10 MM ,
Hose Pipe Working Pressure 40 bars and bursting Pressure 120 bars
Spray Gun Flow rate 1 liter to 53 liters max. at 1 to 55 bars ,drip free shut off Max .horizontal throw 45 feet and vertical throw 38 feet
Auto filler 120 LPM discharge , 50mm hose(length 16 feet)
Educator Nozzle Size: NPT inlet 5x mixer
Total Weight Of Unit 150 kg approximately
Tractor Mounted Sprayer

Tank Capacity : 600 Litters,  Horizontal Agro Chemical Double Layer Tank, Weight : 30 kg

Frame : Made with M.S bars, Weight 120 kg

Drive : Drive by PTO Shaft, Adjustable

Pump : Triple piston, 65 l/min discharge, Three valve, 540 rpm required

Pipe Real : Auto winding Pipe Real System, Capacity up to 400 meter pipe

RPM : 540 rpm require

Accessories :  High jet Gun, 50feet vertical throw and 42 feet horizntal throw

Paint :  Powder Coated

Spare Parts :  Spare Parts kit, all sizes gas kit, tools kit user manual etc.

Grantee : One Year Manufacturer Fault Grantee
